High Volume Low Pressure Spray Gun (15) Low Volume Low Pressure High Adhesion Spray Gun (10)
High Volume Low Pressure Detail Gun (12) Low Volume Low Pressure High Adhesion Detail Gun (2)
High Pressure (13) High Pressure Detail Gun (3)
Pressure Spray Gun (13) Multi-Function Economic Spray Gun (13)
Architecture Spray Gun (Hopper Gun) (8) Auto Spray Gun (4)

HVLP Paint Spray Gun
Product ID: KC-300HS
Specifications:

  • Feed type: Suction
  • Working pressure: 29PSI
  • Air consumption: 6.5CFM
  • Paint flow: 120C.C/min
  • Pattern length: 6-8"
  • Nozzle spec.: 1.3mm, 1.4mm, 1.5mm, 1.8mm, 2.0mm, 2.5mm
Features:

  • Surface painting.
  • Suitable for: Piano, furniture, machinery, car...elegant materials.

HVLP Paint Spray Gun
Product ID: KC-530HG
Specifications:

  • Feed type: Gravity
  • Working pressure: 18PSI
  • Air consumption: 4.0CFM
  • Paint flow: 200C.C/min
  • Pattern length: 6-8"
  • Nozzle spec.: 1.4mm
Features:

  • Surface painting.
  • Suitable for: Piano, furniture, machinery, car...elegant materials.

HVLP Paint Spray Gun
Product ID: KC-800HG
Specifications:

  • Feed type: Gravity
  • Working pressure: 43PSI
  • Air consumption: 10.0CFM
  • Paint flow: 170C.C/min
  • Pattern length: 7-9"
  • Nozzle spec.: 1.3mm, 1.4mm, 1.5mm, 1.7mm, 1.9mm, 2.0mm
Features:

  • Surface painting.
  • Suitable for: Piano, furniture, machinery, car...elegant materials.

HVLP Paint Spray Gun
Product ID: KC-812HG
Specifications:

  • Feed type: Gravity
  • Working pressure: 29PSI
  • Air consumption: 8.0CFM
  • Paint flow: 240C.C/min
  • Pattern length: 6-8"
  • Nozzle spec.: 1.3mm, 1.4mm, 1.5mm, 1.7mm, 1.9mm, 2.0mm
Features:

  • Surface painting.
  • Suitable for: Piano, furniture, machinery, car...elegant materials.

HVLP Paint Spray Gun
Product ID: KC-738HG
Specifications:

  • Feed type: Gravity
  • Working pressure: 29PSI
  • Air consumption: 6.5CFM
  • Paint flow: 110C.C/min
  • Pattern length: 6-8"
  • Nozzle spec.: 1.3mm, 1.4mm, 1.5mm, 1.8mm, 2.0mm, 2.5mm
Features:

  • Surface painting.
  • Suitable for: Piano, furniture, machinery, car...elegant materials.

HVLP Paint Spray Gun
Product ID: KC-538HS
Specifications:

  • Feed type: Suction
  • Working pressure: 29PSI
  • Air consumption: 5.5CFM
  • Paint flow: 175C.C/min
  • Pattern length: 6-8"
  • Nozzle spec.: 1.4mm
Features:

  • Surface painting.
  • Suitable for: Piano, furniture, machinery, car...elegant materials.

HVLP Paint Spray Gun
Product ID: KC-420HSCG
Specifications:

  • Feed type: Gravity
  • Working pressure: 29PSI
  • Air consumption: 5.5CFM
  • Paint flow: 90C.C/min
  • Pattern length: 5-6"
  • Nozzle spec.: 1.3mm, 1.4mm, 1.5mm, 1.8mm, 2.0mm, 2.5mm
Features:

  • Surface painting.
  • Suitable for: Piano, furniture, machinery, car...elegant materials.

HVLP Paint Spray Gun
Product ID: H888W/HVLP
Specifications:

TECHNICAL DATA
Air Pressure Inlet Bar 3
Psi 43
Air Cap Pressure Psi <10
Air Inlet 1/4"
Fluid Inlet M16*1.5P
Air Consumption Cfm 10
L/min 283
Weight Gun Only Lbs 1.17
Kgs 0.53
Capacity Of Cup Liter 0.6NC
Standard Fluid Tip Size mm 1.4
Optional Nozzle Size mm 1.0, 1.2, 1.5, 1.7, 2.0
Repair Kit HW-88RK
Comes Complete With Regulator HW-R3
Optional Alumin Cup HW-0.6AC
HE-1.0AC

HVLP Paint Spray Gun
Product ID: H827W/HVLP/Kit
Specifications:

TECHNICAL DATA
Air Pressure Inlet Bar 3
Psi 43
Air Cap Pressure Psi <10
Air Inlet 1/4"
Fluid Inlet M16*1.5P
Air Consumption Cfm 10
L/min 283
Weight Gun Only Lbs 1.25
Kgs 0.57
Capacity Of Cup Liter 0.6NC
Standard Fluid Tip Size mm 1.4
Optional Nozzle Size mm 1.0, 1.2, 1.3, 1.5, 1.7, 2.0
Repair Kit HW-27RK
Comes Complete With Regulator HW-R3
Optional Alumin Cup HW-0.6AC
HE-1.0AC

HVLP Paint Spray Gun
Product ID: H881W/HVLP
Specifications:

TECHNICAL DATA
Air Pressure Inlet Bar 3
Psi 43
Air Cap Pressure Psi <10
Air Inlet 1/4"
Fluid Inlet M16*1.5P
Air Consumption Cfm 10
L/min 283
Weight Gun Only Lbs 1.14
Kgs 0.52
Capacity Of Cup Liter 1.6NC
Standard Fluid Tip Size mm 1.4
Optional Nozzle Size mm 1.0, 1.2, 1.3, 1.5, 1.7, 2.0
Repair Kit HW-81RK
Comes Complete With Regulator HE-R3
Optional Alumin Cup HW-0.6AC
HE-1.0AC

HVLP Paint Spray Gun
Product ID: H889W/HVLP
Specifications:

TECHNICAL DATA
Air Pressure Inlet Bar 2
Psi 43
Air Cap Pressure Psi <10
Air Inlet 1/4"
Fluid Inlet M16*1.5P
Air Consumption Cfm 12.5
L/min 350
Weight Gun Only Lbs 1.3
Kgs 0.59
Capacity Of Cup Liter 0.6NC
Standard Fluid Tip Size mm 1.5
Optional Nozzle Size mm 1.0, 1.3, 1.7, 2.0
Repair Kit HW-89RK
Comes Complete With Regulator HW-R3
Optional Alumin Cup HW-0.6AC
HE-1.0AC

HVLP Paint Spray Gun
Product ID: H912W/HVLP
Specifications:

TECHNICAL DATA
Air Pressure Inlet Bar 2
Psi 29
Air Cap Pressure Psi <10
Air Inlet 1/4"
Fluid Inlet 3/8"
Air Consumption Cfm 10
L/min 283
Weight Gun Only Lbs 1.19
Kgs 0.54
Capacity Of Cup Liter 0.6NC(M)
Standard Fluid Tip Size mm 1.4
Optional Nozzle Size mm 1.0, 1.2, 1.3, 1.5, 1.6, 1.8
Repair Kit HW-12RK
Comes Complete With Regulator Optional
Optional Alumin Cup HW-0.6AC(M)
HE-1.0AC(M)

HVLP Paint Spray Gun
Product ID: H878W/HVLP
Specifications:

TECHNICAL DATA
Air Pressure Inlet Bar 2
Psi 29
Air Cap Pressure Psi <10
Air Inlet 1/4"
Fluid Inlet 3/8"
Air Consumption Cfm 10
L/min 283
Weight Gun Only Lbs 1.17
Kgs 0.53
Capacity Of Cup Liter 0.6NC(M)
Standard Fluid Tip Size mm 1.4
Optional Nozzle Size mm 1.0, 1.2, 1.3, 1.5, 1.6, 1.8
Repair Kit HW-13RK
Comes Complete With Regulator Optional
Optional Alumin Cup HW-0.6AC(M)
HE-1.0AC(M)

HVLP Paint Spray Gun
Product ID: H878W/HVLP
Specifications:

TECHNICAL DATA
Air Pressure Inlet Bar 2
Psi 29
Air Cap Pressure Psi <10
Air Inlet 1/4"
Fluid Inlet 3/8"
Air Consumption Cfm 4
L/min 112
Weight Gun Only Lbs 0.66
Kgs 0.3
Capacity Of Cup Liter 0.125AC(M)
Standard Fluid Tip Size mm 1.0
Optional Nozzle Size mm 0.5, 0.8, 1.2, 2.0
Repair Kit HW-78RK
Comes Complete With Regulator HW-R8
Optional Alumin Cup -
-

HVLP Paint Spray Gun
Product ID: H828W/HVLP/Kit
Specifications:

TECHNICAL DATA
Air Pressure Inlet Bar
Psi
Air Cap Pressure Psi <10
Air Inlet 1/4"
Fluid Inlet
Air Consumption Cfm
L/min
Weight Gun Only Lbs
Kgs
Capacity Of Cup Liter
Standard Fluid Tip Size mm
Optional Nozzle Size mm 0.5, 0.8, 1.1, 2.0
Repair Kit HW-28RK
Comes Complete With Regulator HW-R8
Optional Alumin Cup HW-0.125AC
-
