- turning work
- milling and bench works
- heat working
- grinding.
The high class of the precision of articles is ensured by
the use of contemporary equipment CNC and by the professionalism
of personnel.
The multi-axis machine centers are established in our production
|
|
|
 |
|
| ZT1000Y |
| Multi-axis Turning Center |
|
|
|
 |
 |
|
| NL2500SY/700 |
| Continuous Machining/ Dual-process
with Y-axis Control Turning Center |
|
|
| The machines NL series were
it is designed as the lathes with the high power
of rotation. NL 2500 can work with the facial drill
with a radius to 80mm. The machines NL of a series
are intended for preparing tools. |
|
|
|
 |
|
| MT1500S |
| Multi-axis Turning Center |
|
|
| The MT series consists of multy
axis turning centers that offer a completely unified
hybridization of the unique functions of both turning
and machinig center. |
|
|
|
| |
|
| Working with the shaft of rotation
along B and Y axes, machine so can work both in
that displaced and in the angular working. The key
advantage consists in shortenings of the period
of production |
|
| Max
turning diametr |
400mm
|
| Max
turning length |
920mm |
| B-axis
rotation range |
120 |
| Max.
spindle speed |
6000 |
| Max
tool spindle speed |
12000
|
| Type
of tool spindle taper hole |
- |
|
Tool storage capacity |
20,40,60,120,180 |
|
| SIZES OF THE MANUFACTURED COMPONENTS |
Maximum diameter of workpiece
- 500mm
Maximum length of workpiece - 1000mm
Maximum area (of flat) workpiece 1000 X 1000 mm
The minimal sizes of the workpiece of 1x1 mm |
| |
|
|
|
 |
|
| BNE51SY |
| The SY-type turning centers
feature an upper turret, a lower turret, a Y-axis
slide for the upper turret, and a sub-spindle. These
new bar machines handle more complex work with higher
productivity to meet the ever-increasing demand
for value-added, multifunctional parts. This new
line provides the capability of a machining center,
enabling you to create highly complex parts surpassing
the limitations of ordinary turning work. |
|
|
|
|
 |
|
| BNJ42S |
| This turning center features
a unique back-working turret and pairing R-spindle
that significantly energize the cutting process
on the right side of the machine. The availability
of greater variation in simultaneous front-and-back
processing speeds up the cycle by approximately
35% compared to conventional machines with two spindles
and one turret. |
|
|
|
|
|
 |
|
| LZ01R |
| Designed to provide secondary
machining on small, lightweight parts that require
relatively short cutting cycles, this self-loading
CNC lathe with live tools offers extremely rapid
loading via the combined movements of the main spindle
and the auto-loader. A built-in work stocker and
other options enable long hours of unmanned operation. |
|
|
|
|
|
 |
|
| BNC-34C5/42C5 |
| The latest models in Miyano's
traditional line of CNC automatics for bar and chuck
work have an excellent reputation for ease of operation
and setup changes. While the basic standard features
are best suited to simple work profiles, the system's
expandability, wide variety of options, and new
NC functions enable you to configure a sophisticated
unmanned manufacturing system. |
|
|
|
|
|
 |
|
| M42J |
- High precision spindle
Quick response built-in spindle
Spindle cooling system is standard
- High rigidity turret
Mounted big diameter curvic coupling (Dia.200)
- High rigidity axis slide
Rigid, wide and square slide guides are used
Less heat-generated Pretensioned ball screw
(X-axis)
|
|
|
|
